You will see our unique advantages in this latest model!

Less Space: 2.6m Height Less Energy Consumption: 1 KVA including Jacquard Wide Purpose: Realized by Computer New Features! By way of RS-232C interface, you can transmit your digital design data directly to D-1 type Air Jet Weaving Loom. Since this is a compact machine, it does not require a big room. With High-speed production, it satisfies the demands of Mass Production as well as Many Items Small Lots.

We have made the full-dress investigation about weaving. Regarding the uses and functions against weaving as well as the requirements of individual fashions, they are diversifying day by day. We firmly believe our D-1 type Air Jet Weaving Loom meets the various needs. We have designed this machine aiming at not only Sample Weaving, Small Lots Weaving but also Mass Production Weaving.

Since we have adapted not Dobby or Cum but Jacquard, you do not need to re-change the Warp Yarn to get it through Heald or Dropper even if weaving structure is changed. Your digital data such as Design, Photo Picture, Weaving Structure, etc., are transmitted by way of RS232C directly to our D-1 type Air Jet Weaving Loom. Less Space and Less Energy Consumption Normally, the height of other manufacturers' machines is more than 4m; however, our D-1 type is only 2.6m Our unique needle selecting system realizes less electric energy consumption compared to other systems. Since we have been manufacturing of both Weaving Loom and Electronic Jacquard, you do not worry about the matching between Loom and Jacquard. Work Efficiency and Safety Margin We have designed D-1 type not to require an expert operator initially. Therefore, even if you do not know how to run our D-1 type, you can operate our D-1 type after taking a couple of lessons. Safety Margin relating to Operating Stuff is naturally considered. An accident caused by miss operating is also considered. We have designed D-1 type not to happen a serious machine trouble caused by miss operating as well as heavy warp yarn breakage. Noise from Weaving Loom is one of new and old problems. However, we have succeeded in reducing it considerably compared to others.

@

@

@

Weaving Loom Specification
Weaving Width 55cm Picking Motion Air Jet System
Weft Yarn Color 4 colors Stop Weft Yarn Feeler
Shedding Electronic Jacquard 1,200 hooks Electronic Consumption 1 KVA including Jacquard
Let off motion Negative Brake System Air Consumption 400 litre/minute
Winding Ratchet Gear System with Stop Motion Device Weight 800 kg including Jacquard
Power Brake Motor 1.5kw
Weft Beating CAM Beating system
Electronic Jacquard
Shedding System Closed, Inclined Shedding Format DOS and CGS Format
Number of Needle 1,248 needles Floppy Disk 3.5" 1.44MB and 3.5" 1.2MB
Needle Selecting System Rocking Solenoid Interface

RS232-C

@

@
